Description
Body Sizes | NPS 1 or 2 / DN 25 or 50 NPS 3, 4, or 6 / DN 80, 100 or 150 NPS 8 x 6 or 12 x 6 / 200 x 150 or 300 x 150 |
---|---|
Materials and End Connections | Cast Iron: NPT, CL125 FF or CL250 RF flanged WCC Steel or CF8M Stainless Steel: NPT, SWE, BWE, CL150 RF, CL300 RF, CL600 RF, or PN 16/25/40 flanged |
Maximum Inlet Pressure (Type EGR Main Valve) | 12.5 psig / 0.86 bar |
Outlet Pressure Ranges | 1/2-inch w.c. to 7-psig / 1.2 mbar to 0.48 bar in eight ranges |
Pressure Registration | External |
Temperature Capabilities | NBR: -20 to 180°F / -29 to 82°C FKM For inches w.c.: 40 to 300°F / 4 to 149°C For psig: 0 to 300°F / -18 to 149°C EPDM: -20 to 275°F / -29 to 135°C FFKM: -20 to 300°F / -29 to 149°C |
Approximate Weights | NPS 1 / DN 25: 85 lbs / 39 kg NPS 2 / DN 50: 100 lbs / 45 kg NPS 3 / DN 80: 145 lbs / 66 kg NPS 4 / DN 100: 195 lbs / 88 kg NPS 6 / DN 150: 380 lbs / 172 kg NPS 8 x 6 / DN 200 x 150: 740 lbs / 336 kg NPS 12 x 6 / DN 300 x 150: 1265 lbs / 574 kg |
Additional Technical Data | For additional technical information, contact your local Sales Office or refer to technical documentation. |
