Description
Pressure Registration | External |
---|---|
Maximum Temperature | Cast Iron Body:?406°F / 208°C | Steel Body: 500°F / 260°C | Optional High-Temperature Steel or Stainless Steel Body: 650°F / 343°C |
Body Sizes | NPS 1 / 1.5 / 2 / 2.5 / 3 / 4 / 6x4 | DN 25 / 40 / 50 / 65 / 80 / 100 / 150x100 |
End Connections | NPT / CL125FF / CL150RF / CL250RF / CL300RF / CL600RF |
Maximum Inlet Pressure | Cast Iron: 250 PSIG / 17.2 bar | Steel: 300 PSIG / 20.7 bar | Or body rating limit, whicever is lower |
Maximum Outlet Pressure | 250 PSIG / 17.2 bar |
Spring Ranges | 2 to 250 PSIG / 0.138 to 17.2 bar |
Additional Technical Data | For additional technical information,?contact?your local?Sales Office?or refer to technical documentation. |
