Description
| Body Sizes and End Connection Styles | WCC Steel: 1 and 2 NPT; NPS 1, 2, 3, 4 and 6 / DN 25, 50, 80, 100 and 150; CL150 RF, CL300 RF or CL600 RF LCC Steel: NPS 8 and 10 / DN 200 and 250; CL150 RF, CL300 RF or CL600 RF Cast Iron: 1 and 2 NPT; NPS 1, 2, 3, 4 and 6 / DN 25, 50, 80, 100 and 150; CL125 FF |
|---|---|
| Pressure Ratings | Maximum Inlet Pressure: 101 bar / 1470 psig or max. body rating Maximum Set Pressure: 101 bar / 1470 psig or max. body rating Minimum Set Pressure: 10 mbar / 4.02-inches w.c. Maximum Shutoff Pressure Differential 100 bar / 1450 psig |
| Manometric Sensing Device Specifications | Spring Ranges: 10 mbar to 72,9 bar / 4.02-inches w.c. to 1058 psig Maximum Sensing Inlet Pressure: 72,9 bar / 1058 psig Setpoint Tolerance: 0,004 bar / 0.058 psig to 12,0 bar / 174 psig Maximum Difference Between Overpressure and Underpressure: 33,0 bar / 479 psig |
| Temperature Capabilities | -30° to 82°C / -22° to 180°F |
| Pressure Sensing Connections | 1/4 NPT |
| Options | Explosion-proof switch Non-explosion-proof limit switch Solenoid Additional manometric device for extra pressure sensing |
